SIM-Teq is a portable wireless training network of simulated dosimeters, survey meters, probes and gamma radiation sources managed and controlled by the Simulation Control Center (SCC) application. The system allows the instructor to combine training instrument auto-response with manual remote-control capability. SIM-Teq enables trainers to create a training environment which includes high fidelity simulated instruments and “live” detectable sources to instill the experience, self-assurance, and real understanding they want trainees to achieve – safely.
The instructor is free to teach, observe and assess the trainee, with the ability to remotely manage or control any SIM-Teq device, individually or collectively. The SCC is an intuitive software application which provides the instructor with the means to view the dynamic measurement and status from all wirelessly connected devices, set source emission levels, model-specific configurations and alarm thresholds, and manually control the displayed measurement, faults and alarms of any training instrument, at any time.
The system is designed to meet the variety of training organization needs to provide frequent, realistic training to provide Radiation Protection Technicians or Emergency Responders with the skills necessary to successfully do their job and/or coordinate together in an actual incident.
All SIM-Teq products are engineered and manufactured by Radiation Safety & Control Services, Inc.
DMC3000TD
The Mirion DMC3000 training dosimeter incorporates an OEM shell, display, sounder and pushbuttons. It looks, feels and operates with most functions supported – identical to a DMC3000 (G2 only) dosimeter. The device pairs with a Rad Tag for auto-response to any TWR Source, or can be controlled directly via the SCC software application. The training dosimeter supports most configuration settings and real dosimeter accessories.
Learn More Download Datasheet Request QuoteRad Tag
The Rad Tag is a battery-operated portable device which wirelessly pairs with any SIM-Teq training dosimeter, enabling the dosimeter to auto-respond to any TWR Source, in addition to the training dosimeters direct control capability. Pairing is temporary and done via the SCC software application.
Learn More Download Datasheet Request QuoteTWR Source
The Two-Way Ranging (TWR) Source is a battery-operated portable device which provides an omni-directional simulated radiation energy field. Each source is identical and can be wirelessly configured via SCC software application to a desired dose rate at one foot – from 1.0 mR/hr to 99,000 R/hr. Training instruments respond to one or more sources following the 1/r2 principle. Range is approximately 100 feet.
Learn More Download Datasheet Request QuoteICTD9-4
The Ludlum 9-4 ion chamber training instrument simulates beta and gamma radiation surveying using active “live” TWR Source(s). The simulator looks, feels and operates like its real counterpart, including the same features and functions. Functional, configurable beta window.
Learn More Download Datasheet Request QuoteTelepoleTD
The TelepoleTD is a training probe which connects to a real Mirion Telepole I telescoping gamma survey meter. The simulated probe is battery operated and provides automatic dose rate input to instrument using active “live” TWR Source(s) and manual dose rate input via SCC. Instrument retains all controls, alarms, and WRM2 telemetry capability. (Mirion Telepole I Telescoping Ratemeter available separately.)
Learn More Download Datasheet Request QuoteRDS-31TD
The RDS-31TD multi-purpose survey training meter simulates gamma radiation surveying using active “live” TWR Source(s). Built with OEM hardware, simulator looks, feels and operates with most functions supported – identical to a RDS-31 survey meter. Supports OEM WRM2 radio for wireless remote monitoring. Configurable units and audible, visual and vibration alarm.
Learn More Download Datasheet Request QuoteGMP-25TD
GMP-25TD is a training probe which connects to the RDS-31TD training meter and simulates the features and functions of the GMP-25 external pancake probe. It provides realistic response based on source/detector geometry using SIM-Teq RFID contamination sources or responds to TWR Source or control manually with SCC. Uses standard probe cable, included.
Learn More Download Datasheet Request QuoteSimulation Control Center (SCC)
Simulation Control Center (SCC) software application for any tablet or PC. Provides wireless control, configuration, and remote viewing of all connected SIM-Teq training products (Dongle required). Direct or group control of one or more training instruments to configure or control all instrument specific features. Up to 32 devices connected at one time per SCC. SIM-Teq product firmware are updated via SCC. The SCC application is free with the purchase of any SIM-Teq device.
Learn More Download Datasheet
